Disco-DFD6363

ABC (Auto Blade Changer)^*

This feature minimizes equipment downtime by automatically detecting the end of blade life and performing all operations from blade replacement to continuing processing in fully automatic operation. It also prevents potential human errors during blade replacement due to workpiece changes and is effective for improved traceability.
*option.

Basic function improvements

DFD6363 offers improved usability through the adoption of a 19-inch monitor and highly visible GUI (Graphical User Interface). It also achieves reduced processing time by optimizing the axis operation through multiple-axis synchronous control. Can expect improved productivity with the improved NCS (Non-Contact Setup)* and stable processing with the mounted specially developed 1.8 kW spindle (60,000 min-1)
*option.


 Operation flow

 (For frame transfer spec.)

1. The lower arm retrieves the workpiece from the cassette. Centering is performed at the pre-alignment stage. The lower arm moves the workpiece to the chuck table. → Cutting →
2. The upper arm moves the workpiece to the spinner table. → Cleaning and drying →
3. The lower arm returns the workpiece to the cassette.
